Vertex
Vertex Vertical Tri Tier Pond Fountain
Vertex Vertical Tri Tier Pond Fountain
Couldn't load pickup availability
The Incredible TriTier
Introducing the Vertex Vertical TriTier Pond Fountain, an exquisite masterpiece that offers a harmonious and captivating water display. This fountain showcases a striking three-tier pattern, adorned with graceful floral arches, meticulously crafted from bronze and brass using precision machining techniques. Choose from a range of heights, ranging from 18 to 26 feet, to create an awe-inspiring focal point. With its delicate balance and intricate design, the Vertical TriTier Pond Fountain brings an air of elegance to any setting. Each water cascade is precisely controlled, ensuring a mesmerizing visual experience for onlookers. Elevate your outdoor space with this stunning fountain, combining artistry and craftsmanship in perfect harmony.
Features & Benefits
- Rugged, commercial-grade construction
- Stainless steel turbine pumps/motors
- Precision machined brass/stainless steel nozzles
- Stainless steel LED lights powered by CREE chips
- More defined, exacting display patterns
- All systems protected with Class A GFCI
- Quicker installations self-leveling design
- Smaller profile for easier handling
- Lower weight reduces freight costs
- Low Maintenance: no oils, 0-rings, or seals to change
- Customize your displays and/or controls
- Competitively priced
- 4-year warranty coverage for display heads, pumps, and motors
- 2-year warranty on LED lighting
- 1-year warranty for the control panel
Technical Specifications
| 2 HP Unit |
3 HP Unit | 5 HP Unit | |
|---|---|---|---|
| Minimum Operating Depth | 6.5' | 6.5' | 6.5' |
| Spray Height (A) | 18' | 23' |
26' |
| Spray Height (B) | 10' | 13' | 12' |
| Spray Height (C) | 4' | 6' | 6' |
| Diameter (D) | 18′ | 23′ | 40′ |
| LED Lights | 2 | 2 | 3 |
| Total Wattage | 86W | 86W | 129W |
| AMP Draw | 0.8 | 0.8 | 1.1 |
| Available Phase | 1 & 3 | 1 & 3 | 1 & 3 |
| 1 Phase (Volts) | 230 | 230 | 230 |
| 3 Phase (Volts) | 208 or 230 | 208 or 230 | 208 or 230 |
| Display Heads Warranty | 4-Year |
4-Year | 4-Year |
| Pumps & Motors Warranty | 4-Year | 4-Year | 4-Year |
| LED Lighting Warranty | 2-year | 2-year | 2-year |
| Control Panel Warranty | 1-Year | 1-Year | 1-Year |
